The Ark series LED display is a 16:9 UHD product developed by LPDISPLAY for both fine pitch rental and fixed LED display market. It is widely used in various performance activities, such as concerts, launch events, e-sports events, industry summits, car shows, and other indoor and outdoor activities.

Pixel pitch:

0.93mm/1.17mm/1.25mm/1.56mm/1.87mm/2.5mm/3.7mm

Brightness:

600-800nits(High brightness optional)

Cabinet size:

600x337.5x73mm

Die-casting
aluminum cabinet

HD display

Easy maintenance

High protection

High refresh rate

Perfect Display Ratio

16:9 golden ratio, seamlessly achieves resolutions including 2k, 4k, and up to 8K for rental quick installation.

The Smallest Pitch in Rental Area: P0.9

Pixel pitch: P0.9,P1.17,P1.25,P1.56,P1.875,P2.5,P3.7 Cabinet size:600x337.5mm

GOB High Protection

Special treatment with GOB technology enables surfaces to be waterproof, dust-proof, impact-resistant, and anti-static.

Multiple Application Scenarios

This product is widely used in various rental scenarios, such as auto shows, press conferences, concerts, and more.

APPLICATION SCENARIOS

Concert

Studio

Car show

Artistic performance

Model	63F09	63F11	63F12	63F15	63F18	63F25	63F37
Pixel Configuration	IMD 4 in 1	SMD	SMD	SMD	SMD	SMD	SMD
Pixel Pitch(mm)	0.93	1.17	1.25	1.56	1.87	2.5	3.7
Cabinet Size(mm)（WxHxD）	600x337.5x73	600x337.5x73	600x337.5x73	600x337.5x73	600x337.5x73	600x337.5x73	600x337.5x73
Cabinet Resolution（WxH）	640x360	512x288	480x270	384x216	320x180	240x128	160x90
Cabinet Weight(kg/cabinet)	7.18	7.18	7.18	7.18	7.18	7.18	7.18
Refresh Rate(Hz)	≥3,840	≥3,840	≥3,840	≥3,840	≥3,840	≥3,840	≥3,840
Grayscale(bit)	14~16	14~16	14~16	14~16	14~16	14~16	14~16
Brightness(nits)	200~4000	200~4000	200~4000	200~4000	200~4000	200~4000	200~4000
Viewing Angle（H/V）	140°/140°	140°/140°	140°/140°	140°/140°	140°/140°	140°/140°	140°/140°
Working Voltage	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz
Lifetime(H)	100,000	100,000	100,000	100,000	100,000	100,000	100,000

Model	63F09	63F11	63F12	63F15	63F18	63F25	63F37
Pixel Configuration	IMD 4 in 1	SMD	SMD	SMD	SMD	SMD	SMD
Pixel Pitch(mm)	0.93	1.17	1.25	1.56	1.87	2.5	3.7
Cabinet Size(mm)（WxHxD）	600x337.5x73	600x337.5x73	600x337.5x73	600x337.5x73	600x337.5x73	600x337.5x73	600x337.5x73
Cabinet Resolution（WxH）	640x360	512x288	480x270	384x216	320x180	240x128	160x90
Cabinet Weight(kg/cabinet)	7.18	7.18	7.18	7.18	7.18	7.18	7.18
Refresh Rate(Hz)	≥3,840	≥3,840	≥3,840	≥3,840	≥3,840	≥3,840	≥3,840
Grayscale(bit)	14~16	14~16	14~16	14~16	14~16	14~16	14~16
Brightness(nits)	200~4000	200~4000	200~4000	200~4000	200~4000	200~4000	200~4000
Viewing Angle（H/V）	140°/140°	140°/140°	140°/140°	140°/140°	140°/140°	140°/140°	140°/140°
Working Voltage	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz	AC 100V~240V,50~60Hz
Lifetime(H)	100,000	100,000	100,000	100,000	100,000	100,000	100,000
